How do you use an aerosol conformal coating? (CTAR-12) - Banner

How do you use an aerosol conformal coating? (CTAR-12)

Shake well. SURFACE MUST BE CLEAN & MOISTURE FREE. Areas not requiring coating should be masked. Coating:  Spray top to bottom, allowing coating to flow around components. Rotate board 90˚ and repeat process 2 or more times.  If nozzle clogs, clean with solvent or use new nozzle. Cure:  A 1.0 mil coating will be tack-free in 30 minutes.  Full cure requires 24 hours @77˚F/25˚C. Heat Cure: 8 hours @170˚F/77˚C. An open vessel of water placed in the drying chamber will facilitate curing. UV detectable for QC inspection. Removal: Coating may be removed by soaking in Electro-Wash® Two Step. Use CircuitWorks® Conformal Coating Remover Pen for spot removal. After the new component is installed, areas should be cleaned and re-coated.
